AAT3123AITP-20-T1

low noise, constant frequency charge pump DC/DC converter, 6 V, 150 mA, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.35~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.35~0.50

PartNumber:: AAT3123AITP-20-T1

Brand:: Advanced Analogic Technologies - AnalogicTech | Pack: TSOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Simmy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-10

From Other Seller

Part Number:AAT3123AITP-20-T1
US $0.35 - 0.50
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AAT3123AITP-20-T1 is a low noise, constant frequency charge pump DC/DC converter that uses a dual mode load switch (1X) and fractional (1.5X) conversion to maximize efficiency for white LED applications. The AAT3123AITP-20-T1 can be used to produce current levels up to 20mA to drive up to six LEDs from a 2.7V to 5.5V input. Outputs may be operated individually or paralleled for driving higher-current LEDs. A low external parts count (two 1uF flying capacitors and two small 1μF capacitors at VIN and OUT) make the AAT3123AITP-20-T1 ideally suited for small battery-powered applications.

Parametrics

AAT3123AITP-20-T1 absolute maximum ratings: (1)VIN Input Voltage: －0.3 to 6 V; (2)VOUT Charge Pump Output: －0.3 to 6 V; (3)FB, VEN/SET FB or EN/SET to GND Voltage: －0.3 to 6 V; (4)VEN/SET(MAX)Maximum EN/SET to Input Voltage: 0.3 V; (5)IOUT 2 Maximum DC Output Current: 150 mA; (6)TJ Operating Junction Temperature Range: －40 to 150 °C.

Features

AAT3123AITP-20-T1 features: (1)Drives Low-VF and High-VF Type LEDs; (2)Up to Six 20mA Outputs (AAT3124); (3)Up to Four 20mA Outputs (AAT3123/23A); (4)32-Position Logarithmic Scale with Digital Control; (5)Simple Serial Control (S2Cwire)Interface; (6)Low Noise Constant Frequency Operation; (7)1MHz Switching Frequency; (8)Small Application Circuit; (9)Regulated Output Current; (10)Automatic Soft Start; (11)No Inductors.
