Product Summary

The MCP6001RT-E is a 1 MHz, low-power op amp which specifically designed for general-purpose applications. The MCP6001RT-E has a 1 MHz Gain Bandwidth Product (GBWP) and 90° phase margin (typ.). It also maintains 45° phase margin (typ.) with a 500 pF capacitive load. This family operates from a single supply voltage as low as 1.8V, while drawing 100 μA (typ.) quiescent current. Additionally, the MCP6001RT-E supports rail-to-rail input and output swing, with a common mode input voltage range of VDD + 300 mV to VSS – 300 mV. This family of op amps is designed with Microchip’s advanced CMOS process. The MCP6001RT-E is available in the industrial and extended temperature ranges, with a power supply range of 1.8V to 5.5V.

Parametrics

MCP6001RT-E absolute maximum ratings: (1)VDD -VSS : 7.0V; (2)All Inputs and Outputs : VSS -0.3V to VDD + 0.3V; (3)Difference Input Voltage : |VDD -VSS|; (4)Output Short-Circuit Current : continuous; (5)Current at Input Pins : ±2 mA; (6)Current at Output and Supply Pins : ±30 mA; (7)Storage Temperature: -65°C to +150°C; (8)Maximum Junction Temperature (TJ): +150°C.

Features

MCP6001RT-E features: (1)Available in SC-70-5 and SOT-23-5 packages; (2)Gain Bandwidth Product: 1 MHz (typ.); (3)Rail to Rail Input/Output; (4)Supply Voltage: 1.8V to 5.5V; (5)Supply Current: IQ = 100 μA (typ.); (6)Phase Margin: 90° (typ.); (7)Temperature Range: Industrial: -40°C to +85°C, Extended: -40°C to +125°C; (8)Available in Single, Dual and Quad Packages.

Diagrams

 SOT23-5  pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MCP6001RT-E/OT
MCP6001RT-E/OT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-1: $0.19
1-10: $0.17
10-25: $0.14
25-100: $0.13
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MCP6001
MCP6001

Other


Data Sheet

Negotiable
MCP6001RT-E/OT
MCP6001RT-E/OT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-1: $0.19
1-10: $0.17
10-25: $0.14
25-100: $0.13
MCP6001RT-I/OT
MCP6001RT-I/OT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-1: $0.16
1-10: $0.14
10-25: $0.12
25-100: $0.11
MCP6001T-E/LT
MCP6001T-E/LT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-2350: $0.13
2350-3000: $0.13
MCP6001T-E/OT
MCP6001T-E/OT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-1: $0.19
1-10: $0.17
10-25: $0.14
25-100: $0.13
MCP6001T-I/LT
MCP6001T-I/LT

Microchip Technology

Operational Amplifiers - Op Amps Single 1.8V 1MHz

Data Sheet

0-1: $0.17
1-10: $0.16
10-25: $0.13
25-100: $0.11
