Product Summary
The ICE2PCS06G is an 8-pin wide input range controller IC for active power factor correction converters. It is designed for converters in boost topology, and requires few external components. The ICE2PCS06G power supply is recommended to be provided by an external auxiliary supply which will switch on and off the IC. The ICE2PCS06G operates in the CCM with average current control, and in DCM only under light load condition. The switching frequency is trimmed and fixed internally at 65kHz. Both current and voltage loop compensations are done externally to allow full user control.
Parametrics
ICE2PCS06G absolute maximum ratings: (1)VCC Supply Voltage VCC: -0.3, 25 V; (2)VINS Voltage VVINS: -0.3, 9.5 V 3); (3)VINS Current IINS: -1, 35 uA; (4)ICOMP Voltage VICOMP: -0.3, 5 V; (5)ISENSE Voltage VISENSE: -20, 5 V 2); (6)ISENSE Current IISENSE: -1, 1 mA Recommended R2=220W; (7)VSENSE Voltage VVSENSE: -0.3, 5 V.
Features
ICE2PCS06G features: (1)Trimmed internal fixed Switching Frequency (65kHz+5% at 25℃); (2)Direct sensing, Input Brown-Out Detection with Hysteresis; (3)Short Startup(SoftStart)duration; (4)Max Duty Cycle of 95% (at 25℃); (5)Trimmed Internal Reference Voltage (3V+2% at 25℃); (6)VCC Under-Voltage Lockout; (7)Cycle by Cycle Peak Current Limiting; (8)Output Over-Voltage Protection; (9)Open Loop Detection; (10)Soft Overcurrent Protection; (11)Enhanced Dynamic Response.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ICE2PCS06G |
Infineon Technologies |
Primary & Secondary Side PWM Controllers |
Data Sheet |
|
|
|||||||||||||
