AT89S8253-24JU

high-performance CMOS 8-bit microcontroller, 7.0V, 15.0 mA, 24 MHz, PLCC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.00~5.00

PartNumber:: AT89S8253-24JU

Brand:: ATMEL Corporation - ATMEL | Pack: PLCC | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Simmy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-30

From Other Seller

Part Number:AT89S8253-24JU
US $2.00 - 5.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT89S8253-24JU is a low-power, high-performance CMOS 8-bit microcontroller with 12K bytes of In-System Programmable (ISP) Flash program memory and 2K bytes of EEPROM data memory. The AT89S8253-24JU is manufactured using Atmels high-density nonvolatile memory technology and is compatible with the industry-standard MCS-51 instruction set and pinout. The on-chip downloadable Flash allows the program memory to be reprogrammed in-system through an SPI serial interface or by a conventional nonvolatile memory programmer. By combining a versatile 8-bit CPU with downloadable Flash on a monolithic chip, the AT89S8253-24JU is a powerful microcontroller which provides a highly-flexible and cost-effective solution to many embedded control applications.

Parametrics

AT89S8253-24JU absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature : -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground : -1.0V to +7.0V; (4)Maximum Operating Voltage : 6.6V; (5)DC Output Current: 15.0 mA.

Features

AT89S8253-24JU features: (1)64-byte User Signature Array; (2)2.7V to 5.5V Operating Range; (3)Fully Static Operation: 0 Hz to 24 MHz; (4)Three-level Program Memory Lock; (5)256 x 8-bit Internal RAM; (6)32 Programmable I/O Lines; (7)Three 16-bit Timer/Counters; (8)Nine Interrupt Sources; (9)Enhanced UART Serial Port with Framing Error Detection and Automatic Address Recognition; (10)Enhanced SPI (Double Write/Read Buffered)Serial Interface; (11)Low-power Idle and Power-down Modes; (12)Interrupt Recovery from Power-down Mode; (13)Programmable Watchdog Timer; (14)Dual Data Pointer; (15)Power-off Flag.
