Product Summary

The AT90CAN64-16AU is a low power CMOS 8 bit microcontroller based on the AVR enhanced RISC architecture. The AT90CAN64-16AU By executing powerful instructions in a single clock cycle, the AT90CAN64-16AU achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. The AVR core combines a rich instruction set with 32 general purpose working registers. All 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one single instruction executed in one clock cycle. The resulting architecture is more code efficient while achieving throughputs up to ten times faster than conventional CISC microcontrollers.

Parametrics

AT90CAN64-16AU absolute maximum ratings: (1)Storage Temperature : -65°C to +150°C; (2)Voltage on any Pin except RESET with respect to Ground : -0.5V to VCC+0.5V; (3)Voltage on RESET with respect to Ground: -0.5V to +13.0V; (4)Voltage on VCC with respect to Ground: -0.5V to 6.0V; (5)DC Current per I/O Pin : 40.0 mA; (6)DC Current VCC and GND Pins: 200.0 mA.

Features

AT90CAN64-16AU features: (1)I/O and Packages: 53 Programmable I/O Lines, 64-lead TQFP and 64-lead QFN; (2)Operating Voltages: 2.7 - 5.5V; (3)Operating temperature: Industrial (-40°C to +85°C); (4)Maximum Frequency: 8 MHz at 2.7V, 16 MHz at 4.5V; (5)JTAG (IEEE std. 1149.1 Compliant)Interface: Boundary-scan Capabilities According to the JTAG Standard, Programming Flash (Hardware ISP), EEPROM, Lock & Fuse Bits, Extensive On-chip Debug Support.

Diagrams

 AT90CAN64-16AU pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AT90CAN64-16AU
AT90CAN64-16AU

Atmel

8-bit Microcontrollers (MCU) CAN AVR UC 64K FLASH SAMPLE

Data Sheet

0-1: $5.28
1-10: $4.40
10-25: $3.31
25-100: $2.99
AT90CAN64-16AUR
AT90CAN64-16AUR

Atmel

8-bit Microcontrollers (MCU) CAN AVR 64K Flash

Data Sheet

0-821: $3.07
821-1000: $3.02
